This list was acquired from an actual Intel Core 2 Quad Q8300 processor with the help of the x86 CPUID instruction. The Q8300 is a 45nm Penryn derived part, and consists of two dual core die's in an MCM multi-chip module module like all other current Core 2 Quad processors. Intel Core2 Duo E8400. Intel Core 2 Quad Q6600 4.5 out of 5 stars 97. Jul 18, 2021 Specifications. Please visit Intel Core 2 Duo E8300 and Intel Core 2 Quad Q8300 pages for more detailed specifications of both microprocessors. / Enhanced SpeedStep. Rows with different specifications or features are highlighted. For detailed specifications of 'Intel Core 2 Duo E8300' or 'Intel Core 2 Quad Q8300' parts please click. Comparison between AMD Ryzen 7 4000 and Intel Core 2 Quad Q8300 with the specifications of the processors, the number of cores, threads, cache memory, also the performance in benchmark platforms such as Geekbench 4, Passmark, Cinebench or AnTuTu.
Cast your vote Do you agree or disagree with CPUBoss?
For detailed specifications of 'Intel Core 2 Quad Q8300' or 'Intel Core 2 Quad Q8400' parts please click on the links in the table header. CPUIDs The table below compares support for x86 extensions and technologies, as well as individual instructions and low-level features of the Intel Core 2 Quad Q8300 and Intel Core 2 Quad Q8400 microprocessors.
Thanks for adding your opinion. Follow us on Facebook to stay up to date with the latest news!
Reasons to consider the IntelCore2 Quad Q8300 | Report a correction |
|
Much better PassMark score | 3,004 | vs | 1,295 | More than 2.2x better PassMark score |
---|
Much better geekbench 2 (32-bit) score | 4,434 | vs | 1,961 | More than 2.2x better geekbench 2 (32-bit) score |
---|
Much newer manufacturing process | 45 nm | vs | 65 nm | A newer manufacturing process allows for a more powerful, yet cooler running processor |
---|
Significantly higher clock speed | 2.5 GHz | vs | 2.13 GHz | More than 15% higher clock speed |
---|
More cores | 4 | vs | 2 | Twice as many cores; run more applications at once |
---|
More threads | 4 | vs | 2 | Twice as many threads |
---|
Much higher Maximum operating temperature | 71.4 °C | vs | 61.4 °C | More than 15% higher Maximum operating temperature |
---|
Newer | Nov, 2008 | vs | Jul, 2006 | Release date over 2 years later |
---|
Reasons to consider the IntelCore2 Duo E6400 | Report a correction |
|
Much lower typical power consumption | 52.81W | vs | 77.19W | More than 30% lower typical power consumption |
---|
Significantly lower annual home energy cost | 15.66 $/year | vs | 22.89 $/year | More than 30% lower annual home energy cost |
---|
Significantly lower annual commercial energy cost | 56.94 $/year | vs | 83.22 $/year | More than 30% lower annual commercial energy cost |
---|
Benchmarks Real world tests of Core2 Quad Q8300 vs Duo E6400
GeekBench 3 (Multi-core)Data courtesy Primate Labs
Driver Intel Core 2 Quad Q8300 Vs Core I7
GeekBench 3 (Single core)Data courtesy Primate Labs
Driver Intel Core 2 Quad Q8300 Vs Core Processor
GeekBench 3 (AES single core)Data courtesy Primate Labs
summary | Core2 Quad Q8300 | vs | Duo E6400 |
---|
Clock speed | 2.5 GHz | 2.13 GHz |
---|
Cores | Quad core | Dual core |
---|
Socket type |
---|
LGA 775 |
features |
---|
Has a NX bit | Yes | Yes |
---|
Supports trusted computing | No | No |
---|
Has virtualization support | Yes | Yes |
---|
Instruction set extensions |
---|
SSE2 |
MMX |
SSE3 |
SSE |
SSE4.1 |
Supplemental SSE3 |
Supports dynamic frequency scaling | Yes | Yes |
---|
power consumption |
---|
TDP | 95W | 65W |
---|
Annual home energy cost | 22.89 $/year | 15.66 $/year |
---|
Annual commercial energy cost | 83.22 $/year | 56.94 $/year |
---|
Performance per watt | 1.39 pt/W | 1.35 pt/W |
---|
Typical power consumption | 77.19W | 52.81W |
---|
bus |
---|
Architecture | FSB | FSB |
---|
Number of links | 1 | 1 |
---|
Clock speed | 1,333 MHz | 1,066 MHz |
---|
Driver Intel Core 2 Quad Q8300 Vs Core I5
details | Core2 Quad Q8300 | vs | Duo E6400 |
---|
Architecture | x86-64 | x86-64 |
---|
Threads | 4 | 2 |
---|
L2 cache | 4 MB | 2 MB |
---|
L2 cache per core | 1 MB/core | 1 MB/core |
---|
Manufacture process | 45 nm | 65 nm |
---|
Transistor count | 456,000,000 | 167,000,000 |
---|
Max CPUs | 1 | 1 |
---|
Clock multiplier | 7 | 8 |
---|
Voltage range | 0.85 - 1.36V | 0.85 - 1.5V |
---|
Operating temperature | Unknown - 71.4°C | Unknown - 61.4°C |
---|
overclocking |
---|
Overclock popularity | 23 | 15 |
---|
Overclocked clock speed | 3.32 GHz | 3.33 GHz |
---|
Overclocked clock speed (Water) | 3.33 GHz | 3.33 GHz |
---|
Overclocked clock speed (Air) | 3.32 GHz | 3.33 GHz |
---|
integrated graphics |
---|
GPU | None | None |
---|
Label | N/A | N/A |
---|
Latest DirectX | N/A | N/A |
---|
Number of displays supported | N/A | N/A |
---|
GPU clock speed | N/A | N/A |
---|
Turbo clock speed | N/A | N/A |
---|
3DMark06 | N/A | N/A |
---|
